DJF-500H Continuous Fruits Vegetable Stretch Film Wrapper

Our automatic cling-film packaging machine is designed for wrapping fresh produce — fruits, vegetables, fresh meat — as well as ready-to-eat processed foods. It is ideal for major supermarket chains, distribution hubs, and produce bases. By automating the wrapping process, this machine significantly reduces labor costs and greatly improves operational efficiency. As a result, retailers and producers can enjoy faster turnaround times and more consistent, hygienic packaging.


Product Detail

Technology specifications

Model

DJF-500H

Machine Dimensions(mm)

3185 × 1015 × 1372

Machine Material

304 Stainless Steel

Length of Packing Items(mm)

120-350

Width of Packing Items(mm)

95-220

Height of Packing Items(mm)

10-130

Weight of Packing Items(g)

50-4500

Width of Film(mm)

350-550

Max. Diameter of Film(mm)

160

Working Humidity(%RH)

10-90

Environment Temperature(℃)

10-30

Voltage(V)

220

Frequency(Hz)

50

Max. Packing Speed(Pcs/min)

25

Power Consumption(kw)

1400

N.W(kg)

275

Shipping Dimensions(mm)

2500 × 1220 × 1260

微信图片_20200815104512x

Technical characters

  • Control System: The PLC control panel provides several control modes for user’s selection.
  • Material of Main Structure: 304 stainless steel.
  • Display Screen: TFT 10.2 inch colour human-computer interface touch screen.
  • Operation Way: Mechanical press button and high precision touch operation.
  • Heavy Duty Casters: The heavy duty casters on the machine features superior loading bearing performance, so that the user may move the machine with ease.
  • Electrical requirement and plug could be custom according to customer requirement.
